Interior cleaning heads HKF 50 P

The ATEX-certified, pneumatically driven stainless steel HKF 50 P interior cleaning head cleans small and medium-sized tanks up to 1000 l.

The pneumatically driven compact HKF 50 P interior cleaning head is designed to clean inside vats and containers up to approx. 1000 litres (e.g. IBC tanks). The pneumatic drive ensures a constant rotational speed irrespective of the flow or pressure of the cleaning agent. The use of premium materials such as stainless steel on parts in contact with media, and PTFE sealings on the shafts ensure a long service life. The low weight (7 kg) means there is no need for extra suspension devices (spring balancers or hoists). Operational up to 100 bar, up to 1200 l/h and up to 95 °C water temperature. The head measures 715 millimetres in length and the maximum immersion depth is 304 millimetres. If required, the immersion depth of the head can be as much as 1500 millimetres. The cleaning head can be easily connected to a cold-water or hot-water pressure washer via a high-pressure hose. Various accessories such as bunghole cone, racks, spray nozzles, pipe elbows and high-pressure hoses open up a wide range of applications. Required air pressure: 4 to 7 bar. The HKF 50 P interior cleaning head is ATEX-certified and can be used in explosion-proof areas.

Features and benefits
Compact dimensions
  • Suitable for cleaning inside containers with narrow openings from 50 mm.
  • Can be used in different applications.
Compressed air operation
  • Suitable for cordless use.
ATEX certification (protection against explosion)
  • High safety standard in accordance with legal requirements.
  • For use in explosion-protected systems.
No hoists/balancers are needed to suspend the head
Low weight
  • Saves on additional installation and maintenance costs.
  • Easy handling – Manual operation of the head in the container.
Intelligent design
  • First-class cleaning results.
  • No pressure drop as a result of friction loss.
  • Ease of operation.
Industrial standard (components that come into contact with cleaning medium are stainless steel)
Different nozzle configuration
  • Long service life ensures costs are saved.
  • Robust interior cleaning head for lower maintenance costs and long working times.
  • A large number of different small containers such as IBC containers can be cleaned.
Different nozzle configuration
Specifications

Technical data

Drive Pneumatic
Compressed air (bar) 4 - 7
Operating pressure (bar) 100
Weight without accessories (kg) 7
Application areas
  • For cleaning inside tanks (industry, logistics, public services)
  • Also suitable for cleaning inside IBC containers (tanks)
  • For container/deposit cleaning in the food, cosmetics and chemicals industries
  • For cleaning containers used for transporting chemical products
  • For cleaning containers used for transporting food
