Spray-extraction cleaner Puzzi 10/1

The Puzzi 10/1 is ideal for cleaning smaller to medium-sized carpets, upholstery and textile flooring. The modular accessories are kept directly on the machine. The carrying handle offers a clip for the wand and makes transportation easy.

Perfectly suitable for everyday use. With a powerful 12.5 PSI spray rate, the water and detergent solution is applied to the area being cleaned and picked up immediately by the vacuum nozzle. Cleaned surfaces can be walked on almost right away as very little residual moisture remains. Carpets dry up to 63% faster than those cleaned with other comparable products.

Features and benefits
Spray-extraction cleaner Puzzi 10/1: Optimal suitability for daily use
Optimal suitability for daily use
Tool-free adjustment of the grip; Accessory/cable fastenings; quick change from floor to upholstery nozzle.
Spray-extraction cleaner Puzzi 10/1: Removable dirty water tank
Removable dirty water tank
The dirty water tank is easy to remove and can also be used for filling the fresh water tank.
Spray-extraction cleaner Puzzi 10/1: Diverse use
Diverse use
Various accessories for diverse applications (e.g. crevice nozzle for cleaning car seats and upholstery).
Ergonomic two-handed grip
  • Lightweight with an ergonomically designed handle for ease of operation.
  • Height-adjustable handle.
Specifications

Technical data

Max. area performance (m²/h) 20 - 25
Air flow (l/s) 54
Vacuum (kPa) 22
Spray rate (l/min) 1
Spray pressure (bar) 1
Fresh/dirty water tank (l) 10 - 9
Turbine capacity (W) 1250
Pump capacity (W) 40
Voltage (V) 110 - 127
Weight without accessories (kg) 10.7
Dimensions (L × W × H) (mm) 690 x 325 x 440

Equipment

  • Spray hose with integrated water feed, 2.5 m
  • Integrated accessory storage for hand nozzle
  • Upholstery nozzle
  • RM 760 tablets, 2 piece(s)
  • Additional handle
  • Cable hook
  • Narrow floor nozzle with flexible suction lip
  • Handle with trigger
