High-pressure washer HD 2.3/14 C Ed Food

Unheated, compact HD 2.3/14 C Ed Food high-pressure cleaner. Designed for universal use in the commercial food industry and equipped with the new EASY!Force high-pressure gun.

Specifically developed for the commercial food industry: the unheated HD 2.3/14 C Ed Food high-pressure cleaner. With high-quality equipment, the top model in the Compact class has an upright and exceptionally robust construction style and impresses with a high level of mobility, easy operation and the long service life of its individual components. With the EASY!Force high-pressure gun, which makes use of the recoil force of the high-pressure jet to reduce the holding force for the operator to zero, as well as the EASY!Lock quick-release fasteners, which make set-up and dismantling five times faster than with conventional screw connections, the machine is very convenient to use. The included triple nozzle for quick spray adjustment also significantly increases operator convenience. Thanks to the cleaning agent dosing valve, cleaning agents can be added to the high-pressure jet in the low pressure range. A range of useful details, like the generous storage possibilities for accessories, cable storage and a nozzle compartment round off the complete package.

Features and benefits
High-pressure washer HD 2.3/14 C Ed Food: Save time and energy: EASY!Force high-pressure gun and EASY!Lock quick-release fasteners
Save time and energy: EASY!Force high-pressure gun and EASY!Lock quick-release fasteners
Fatigue-free work at last: the EASY!Force high pressure gun. EASY!Lock quick-release couplings: durable and robust. And five times faster than screws.
High-pressure washer HD 2.3/14 C Ed Food: High standard of hygiene
High standard of hygiene
Food-grade, non-marking pressure hose. Abrasion-resistant grey wheels. Water inlet temperature up to 80°C.
High-pressure washer HD 2.3/14 C Ed Food: Practical detergent system
Practical detergent system
Cleaning agent suction system for stubborn dirt. The "Inno Foam Set" high-pressure foam system can be used if required.
Infinitely variable pressure/water flow regulation
  • Directly on the machine.
  • Gentle cleaning of sensitive surfaces.
Specifications

Technical data

Supply voltage (Ph/V/Hz) 1 / 120 / 60
Flow rate (l/h) 520
Inlet temperature (°C) 80
Working pressure (bar/MPa) 10 - 97 / 1 - 9.7
Max. pressure (bar/MPa) 117 / 11.7
Connected load (kW) 2.4
Weight (with accessories) (kg) 33.4
Weight incl. packaging (kg) 36.6
Dimensions (L x W x H) (mm) 360 x 375 x 925

Scope of supply

  • Spray gun: EASY!Force Food
  • High-pressure hose: 15 m, Food design
  • Stainless steel spray lance: 840 mm
  • Triple nozzle (0°/ 25°/40°): manual

Equipment

  • Pressure switch-off
High-pressure washer HD 2.3/14 C Ed Food
High-pressure washer HD 2.3/14 C Ed Food
High-pressure washer HD 2.3/14 C Ed Food
High-pressure washer HD 2.3/14 C Ed Food
High-pressure washer HD 2.3/14 C Ed Food
